Product Image DH Prime Focus C Band Dual Linear Feed Big Dish BUD Commercial C-band

DH Prime Focus C Band Dual Linear Feed Big Dish BUD Commercial C-band

$259.99


Description:
DH Satellite’s Dual C band feed offers
simultaneous reception of horizontal and
vertical C band polarities from 3.4 to 4.2GHz.
Ideal C band linear feed for commercial
installation.


Specifications:
Part Number: 1339C
Input Frequency: 3.4 – 4.2GHz
f/D Ratio: .30 ‐ .42
Cross pol Isolation: 35db min
VSWR: 1.5:1.0
RF Port: WR 229
Temperature Range: ‐40˚C to +60˚C
Number of Ports: 2
Polarization: Linear
Weight: 2.5 lbs approx.


Features:
 Adjustable Scalar Ring
 Cast Aluminum Construction
 Mounts to all Standard Feed
Supports
